Asus TS700-X7/PS4 User Manual

6-2
Chapter 6: RAID conguration
Chapter 6
6.1.3 Setting the RAID item in BIOS
You must set the RAID item in the BIOS Setup before you can create a RAID
set from SATA hard disk drives attached to the SATA connectors supported by
Intel
®
C602 chipset. To do this:
1. Enter the BIOS Setup during POST.
2. Go to the
Advanced
Menu >
PCH SATA Conguration
, then press <Enter>.
3. Set
SATA Mode
to [RAID Mode]
4. Press <F10> to save your changes and exit the BIOS Setup.
Refer to Chapter 4 for details on entering and navigating through the BIOS
Setup.
6.1.4 RAID conguration utilities
Depending on the RAID connectors that you use, you can create a RAID set using
the utilities embedded in each RAID controller. For example, use the
LSI Software
RAID Configuration Utility
or the
Intel
®
Rapid Storage Technology
if you
installed Serial ATA hard disk drives on the Serial ATA connectors supported by the
Intel
®
C602 chipset.
Refer to the succeeding section for details on how to use the RAID conguration
utility.
6.1.2 Installing hard disk drives
The motherboard supports Serial ATA for RAID set configuration. For optimal
performance, install identical drives of the same model and capacity when creating
a disk array.
To install the SATA hard disks for RAID conguration:
1. Install the SATA hard disks into the drive bays following the instructions in the
system user guide.
2. Connect a SATA signal cable to the signal connector at the back of each drive
and to the SATA connector on the motherboard.
3. Connect a SATA power cable to the power connector on each drive.
