Asus TUF X470-PLUS GAMING User Manual

1-2
Chapter 1: Product Introduction
Chapter 1
Referto1.1.7Internal connectorsand 2.2.1 Rear I/O connectionformoreinformation
aboutrearpanelconnectorsandinternalconnectors.
1.1.2 Motherboard layout
®
DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_A2* (64bit, 288-pin module) DDR4 DIMM_B1 (64bit, 288-pin module) DDR4 DIMM_B2* (64bit, 288-pin module)
AIO_PUMP
CPU_FAN
CHA_FAN2
CHA_FAN3
CHA_FAN1
CLRTC
SPDIF_OUT
M.2_2(SOCKET3)
M.2_1(SOCKET3)
PANEL
AAFP
COM
SATA6G_6 SATA6G_5
EATX12V
EATXPWR
U31G1_12
U31G1_34
AMD
®
X470
RTL
8111H
U31G2_12
HDMI
U31G1_C7
Super
I/O
PCIEX1_1
PCIEX1_2
228022110 2260 2242
2280 2260 2242
PCIEX1_3
PCIEX16_1
PCIEX16_2
USB1314 USB1112
RGB_HEADER
LAN_U31G1_56
KBMS_910
DVI
DIGI
+VRM
24.4cm(9.6in)
30.5cm(12in)
BATTERY
SOCKET AM4
AUDIO
SATA6G_1SATA6G_2
SATA6G_3SATA6G_4
256Mb
BIOS
7
6
5
1
8
2
8
911121314
1
4
2 23
6 810

Asus TUF X470-PLUS GAMING Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200 MHz
Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD Athlon, AMD Athlon X4, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	32 Mbit
System Management BIOS (SMBIOS) version	3.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111H
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	AMD X470
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64
Cables included	SATA

Weight and Dimensions

Depth	244 mm
Width	305 mm
