Asus VS278 Series User Manual

2-2 Chapter 2: Setup
2.3 Detaching the arm/base
(for VESA wall mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the rubbers in the four screw holes. (Figure 1)
3. Remove the base (Figure 2).
4. Pry the rear hinge cover (Figure 3).
5. Use a screwdriver to remove the four screws on the hinge (Figure 4), then
remove the hinge.
1
2
Figure 1 Figure 2
Figure 3 Figure 4
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.

Asus VS278 Series Specifications

General

Screen Size	27 inches
Resolution	1920 x 1080 (Full HD)
Panel Type	TN
Refresh Rate	60 Hz
Response Time	1 ms (GTG)
Aspect Ratio	16:9
Brightness	300 cd/m²
Contrast Ratio	1000:1
Viewing Angle	170°(H)/160°(V)
Dynamic Contrast Ratio	80, 000, 000:1
Ports	HDMI, DVI, VGA
