2-3ASUS VS278 Series LCD Monitor
2.4 Connecting the cables
Connect the cables as the following instructions:
HDMI-2 VGA
VGA
HDMI
HDMI-1
HDMI
Displayport
Earphone jack
Audio-in
: connect one end of the power cord securely to
the monitor’s AC input, the other end to a power outlet.
:
a. Plug one end of the VGA/HDMI/DisplayPort cable to the monitor’s VGA/
HDMI/DisplayPort port.
b. Connect the other end of the VGA/HDMI/DisplayPort cable to your
computer's VGA/HDMI/DisplayPort port.
c. Tighten the two screws to secure the VGA connector.
connect one end of the audio cable to the
monitor’s Audio-in port, the other end to the computer’s audio-out port.
: connect the end with plug type to the monitor’s earphone jack.
When these cables are connected, you can choose the desired signal from the
Input Select item in the OSD menu.
2.5 Turning on the monitor
Press the power button . See page 1-2 for the location of the power button. The
power indicator lights up in blue to show that the monitor is ON.
