Z7S WS specications summary
(continued on the next page)
CPU
Dual LGA771 sockets for Dual-Core Intel
®
Xeon™
processors 5100/5200 sequences and Quad-Core
Intel
®
Xeon™ processor 5300/5400 sequence
Supports Intel
®
Extended Memory 64Technology (EM64T),
EIST, VT, XD, and TM/TM2
Chipset
MCH: Intel
®
Seaburg
ICH: Intel
®
ESB2E
System Bus
1600 / 1333 / 1066 MHz
Memory
Quad-channel memory architecture
6 x 240-pin FB-DIMM sockets support registered ECC
fully buffered DDR2 800 / 667 / 533 memory modules
with Advanced Memory Buffer (AMB chip)
Supports 512 MB up to 24 GB system memory
Supports memory sparing technology.
Expansion Slots
1 x PCI Express™ x1 MIO slot
2 x PCI Express™ 2.0 x16 slots (x16 link)
1 x PCI-X 133/100 MHz/64bit/3.3V slot
1 x PCI 33 MHz/32-bit/5V slot
1 x Universal PCI Express™ x16 slot (x8 link)
Storage Intel
®
ESB2E ICH
- 1 x Ultra DMA 100/66/33 devices
- 6 x SATA II (3.0 Gb/s)
- Intel
®
Matrix Storage with RAID 0, 1, and 5 (S/W)
conguration
JMicron
®
JMB363 SATA controller
- 2 x External SATA 3 Gb/s ports (SATA On-the-Go)
- Supports SATA RAID 0, 1, and JBOD conguration
LAN
2 x Marvell
®
88E8056 Gigabit LAN controllers
- Supports teaming function
High Denition audio
Realtek
®
888S 8-channel High-Denition Audio CODEC
- Supports Jack-Sensing, Multi-streaming, and Jack-Supports Jack-Sensing, Multi-streaming, and Jack-
Retasking Technology
- Coaxial / Optical S/PDIF out ports at back I/O
- ASUS Noise Filter
IEEE 1394
VIA 6308S controller supports 2 x IEEE 1394a ports (one
at midboard; one at back panel)
USB
Supports up to 8 USB 2.0 / 1.1 ports (3 at mid-board, 5 at
back panel)
