ASUS Z7S WS 4-27
Power On By RTC Alarm [Disabled]
Allows you to enable or disable RTC to generate a wake event. When this item is
set to [Enabled], the items RTC Alarm Date/ RTC Alarm Hour/ RTC Alarm Minute/
RTC Alarm Second will become user-congurable with set values.
Conguration options: [Disabled] [Enabled]
Power On By PS/2 Keyboard [Disabled]
Allows you to disable the Power On by PS/2 keyboard function or set specic keys
on the PS/2 keyboard to turn on the system. This feature requires an ATX power
supply that provides at least 1A on the +5VSB lead.
Conguration options: [Disabled] [Space Bar] [Power Key] [Ctrl-Esc]
4.5.6 Hardware Monitor
Scroll down to display the following items:
v02.61 (C)Copyright 1985-2007, American Megatrends, Inc.
VTT Voltage [1.210V]
FBD +1.5V Voltage [1.488V]
FBD +1.8V Voltage [1.808V]
3V Voltage [2.960V]
12V Voltage [12.986V]
5V Voltage [5.094V]
5VSB Voltage [5.046V]
VBAT Voltage [3.008V]
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2007, American Megatrends, Inc.
Hardware Monitor
CPU0 Temperature [34ºC/93ºF]
CPU1 Temperature [N/A]
MB Temperature [39ºC/102ºF]
Memory Temperature [33ºC/91ºF]
CPU0 Fan Speed [2372RPM]
CPU1 Fan Speed [N/A]
Chassis Fan 1 Speed [N/A]
Chassis Fan 2 Speed [N/A]
Chassis Fan 3 Speed [N/A]
Chassis Fan 4 Speed [N/A]
SPS Fan1 Speed [N/A]
FBD Fan1 Speed [3913RPM]
Smart Fan Control [Enabled]
CPU0 Target Temperature [55]
CPU1 Target Temperature [55]
MB Target Temperature[45]
VCORE0 Voltage [1.072V]
VCORE1 Voltage [N/A]
CPU0 Temperature
BIOS SETUP UTILITY
Power
CPU0/1 Temperature [xxxºC/xxxºF]
MB Temperature [xxxºC/xxxºF]
Memory Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU(s),
motherboard and memory temperatures. Select [Ignored] if you do not wish to
display the detected temperatures.
