Atlas Copco GX 11 User Manual

Ref. Name
1 Control panel
AF Air filter
AO Air outlet
AR Air receiver
Ca Air cooler
Co Oil cooler
Da Automatic drain
Dm1 Manual condensate drain
DR Dryer
E Compressor element
OF Oil filter
OS Oil separator
OT Oil separator tank
GX Full-feature
An air cooler (Ca) and an air dryer (DR) are integrated into the bodywork. A condensate drain system is
provided including a valve for automatic draining during operation (Da) and a manual drain valve (Dm1).
GX Pack
The compressor is not fitted with an air cooler, air dryer and condensate drain system as standard.
Instruction book
2920 7054 00 11

Atlas Copco GX 11 Specifications

General

Brand	Atlas Copco
Model	GX 11
Category	Air Compressor
Language	English
