2.3 Oil system
GX 7 and GX 11 Pack
GX 7 and GX 11 Full-Feature
Air pressure forces the oil from oil separator/tank (OT) through oil cooler (Co) and filter (OF) to compressor
element (E) and the lubrication points. In oil separator/tank (OT), most of the oil is removed centrifugally;
the rest is removed by separator (OS).
Instruction book
14 2920 7054 00
