2.7 Protection of compressor
Electric cubicle
Legend
Ref. Designation
(1) only on Full Feature versions
(2) only on multi-voltage versions
Ref. Designation
F1-2-3-4-10 Fuses (F10 only on Full Feature units - see (1) on figure)
FM1 Motor overload relay
KL Line contactor
