2 General description
2.1 Introduction
Introduction
GX 2 EP, GX 3 EP, GX 4 EP, GX 5 EP and GX 7 EP are air-cooled, single-stage, oil-injected screw
compressors, driven by an electric motor.
The compressors are belt driven.
The compressors are enclosed in sound-insulating bodywork.
An easy-to-operate control panel is provided, including the start/stop switch and the emergency stop button.
A cabinet housing the regulator, pressure switch and motor starter is integrated into the bodywork.
Pack versions do not include an air dryer.
Full-Feature versions are fitted with an air dryer (DR). The dryer removes moisture from the compressed air
by cooling the air to near the freezing point and automatically draining the condensate.
Floor-mounted model
The compressor is installed directly on the floor.
The floor-mounted model is available as Pack version only.
GX 5 Pack EP, floor-mounted
Ref. Description
1 Control panel
Instruction book
2920 7105 31 9
