3 Installation
3.1 Installation proposal
Outdoor/altitude operation
If the compressor is installed outdoors or if the ambient temperature can be below 0˚C (32˚F), precautions
must be taken. In this case, and also if operating at high altitude, consult Atlas Copco.
Moving/lifting
Transport by a pallet truck
To prevent a tank-mounted model from falling over during transport by a pallet truck: push
the forks underneath the air receiver and place a wooden beam (1) (cross-section approx.
4 x 6 cm / 1.6 x 2.4 in) through the supports on both sides of the receiver. While holding
the compressor, slowly lift the forks until the receiver is secured between the beams.
Instruction book
30 2920 7105 31
