(9) Manual condensate drain
(10) Power switch, dryer
(11) Power switch, compressor
GX 7 Full-Feature on 200 l receiver
(1) Power supply cable, dryer
(2) Power supply cable, compressor
(3) Cooling air inlet
3.3 Electrical connections
Always disconnect the power supply before working on the electrical circuit!
Instruction book
2920 7105 31 37
