Atlas Copco MINI-REG-1/4-BSP User Manual

Installation EN MINI-REG, MIDI-REG, MAXI-REG
8
© Atlas Copco Industrial Technique AB - 9839 1513 01
Mounting the gauge
To mount the gauge:
1. Turn the gauge into the gauge thread, using a size 14 open-end wrench. Turn until the seal has been
completely screwed onto the thread.
2. Align the manometer by turning it clockwise or counterclockwise up to ¾ of a turn. Maximum screw-
ing-in torque: 8 Nm (71 in.lbs).

Atlas Copco MINI-REG-1/4-BSP Specifications

General

Brand	Atlas Copco
Model	MINI-REG-1/4-BSP
Category	Controller
Language	English
