UNINTENDED USE
The reliability of the pump is only guaranteed when it
is used according the specifications in this manual.
The limits as indicated are not to be exceeded under
any circumstances.
Do not use the pump to transport water for human
consumption, for water well pumping or for
installation in an explosive atmosphere.
Caustic, slightly inflammable and other explosive
substances such as petrol, petroleum, diluted
nitrogen, greases, oils, salt water and waste water
from toilets as well as sludgy water that has a slower
flow capacity than water, should not be transported
using the pump.
The temperature of the transported fluids should not
exceed 40°C.
The appliance is not suitable for use as a stationary
installation (such as a lifting device, fountain pump).
DATA PLATE
Reference Name
1 Serial number
2 Pump type
3 Protection class
4 Production year
5 Rated voltage
6 Motor insulation class
7 Rated rpm
8 Rated current
9 Max. flow capacity
10 Rotation direction
11 Start kick direction
12 Weight
13 Max. head
14 Rated power input
15 Frequency
16 Number of phases
17 Max. fluid temperature
18 Max. submersed depth
19 Approval mark (CE, UL, CSA, ...)
