Voorzijde – detail
Achterzijde – detail
Indicatie LED
s
Power schakelaar
Ventilator
Power
indicatie
LED
24VDC input
terminal
AC power input
connector met
zekeringhouder
*
Luidspreker connection
terminal (4Ω, 70V,
100V en COM)
Level adjustment knop
HPF (400Hz)
on/off schakelaar
Signaal
input en
link output
connectors
Ground schakelaar
(bescherming tegen
ground loop)
Luchtstroom
*
Voltage
Model
115/120 Vac 220/230/240 Vac
CPA12
T4AL / 250V T3.15AL / 250V
CPA24
T8AL / 250V T4AL / 250V
CPA36
T12AL / 250V T6.3AH / 250V
Idem CPA 12 & 24
Idem CPA 12 & 24
