Technical Data
Looper Threading System: Jet Air Threading for chain looper
Tension Dials: Dials for Chain/Cover stitch needles
Stitch Length Dial: 1.0-4.0mm
Differential Feed Ratio: 0.6 to 2.0
Presser Foot: Snap On Foot
Looper Chain Looper
Needle System: Organ ELx705CF #80/12 and #90/14
Number of Needles: 3 - C-1,C-2,C-3
Sewing Speed: Up to 1500 s.p.m.
Machine Weight: 7.3 kg/16 2bs.
Light Bulb: 15W / 110V or 10W / 240V
Stitch Types: Chain Stitch
- Right (C-1), Center (C-2), Left (C-3)
Cover Stitch
- Narrow Left
- Narrow Right
- Wide
- Triple
Stitch Width: Cover Stitch
- Triple Cover Stitch : 6.0mm
- Cover Stitch - Wide : 6.0mm
- Cover Stitch - Narrow: 3.0mm
