35
AVAILABLE BLANKING PLATES
DOOR BOARD PINOUT
A5PL8900 Plate used for Bill Validator A5PL9995 Plate used instead of ticket dispenser
A5PL4200 DBA Plate for 12V Upstacker Bill Acceptor A5PL9998 Plate used instead of Coin Mechanisms
