22
CIRCUIT BOARD LAYOUT
Circuit Board Layout
AACB5156
Power Dist. Board
A5CB2204A
Interface Board
AACB5900
Light Board
J16
J18
J22
J25
J8
J21
J24
J19
J29
J6
AANEWGEN1-PJ/RBN
J5
AACE5914
Com with
Motherboard
USB Socket
to Update
Software
AACE5921
Bill Acceptor
AACE5920
Coin Door
+12 V
Signal
Com
AACE5912
12 Volt DC
Power In Cable
AACE5910
Menu Buttons
AACE5920
LED control
AACE5909
Stop Light
AACE5908
Cable to
Speaker
AACE3306
Ribbon Cable to
Light Board
AACE5911
Ticket Dispenser
AACE5911
Low Ticket Switch
A5CEAU010
Sound Input From
Motherboard
J9
AACE5910
Counters
AAMB9A-SHD
Motherboard
