Bay-Tek Pop the Lock User Manual

37
PARTS LIST
17
PART # DESCRIPTION
PART # DESCRIPTION
A5ME5900 METAL,BOTTOM RAIL
A5BK1013 BRACKET,PUSHBUTTON/COUNTERS
A5BK6035 BRACKET,LIGHT
A5CB1499 COIN BOX
A5CN1031 CONN,ADAPTER 9POS F-RJ45
A5CO4203 COVER,SPEAKER
A5CORD5 CORD,AC COMPUTER CORD
A5DE0042 DECAL, NEW MENU/VOLUME POT
A5DE0048 DECAL, UNIVERSAL CARD LINK
A5DE0114 DECAL,CIRCLED GROUND STUD
A5FI9010 FILTER,INLINE,TO PASS FCC
A5LK2001 LOCK, CASH BOX, A05/E00 KEY
A5LK5002 LOCK, 7/8", H95 KEY CODE
A5PB5900 PUSH BUTTON,RED,W/LEDS
A5SW200 LOW TICKET SWITCH
A5TD1 TICKET DISPENSER,ENTROPY
A5TT4000 TICKET TRAY
A5VF5901 VACUUM FORM,PLAYFIELD
A5VF5902 VACUUM FORM,HASP
A5VF5903 VACUUM FORM,BUTTON HOUSING
A5MO5500 MONITOR/TV,55"
A5PL8900 PLATE,BLANKI,BILL VALIDATOR
A5OU1000 OUTLET,STRIP,SIX,15AMP,125V
A5CORD35A CORD,15',HDMI W/FERRITE CORES
A5DE5900 DECAL,BUTTON BASE
A5DE5901 DECAL,CONTROL PANEL
A5DE5902 DECAL,CABINET FRONT
A5DE5903 DECAL,MECH DOOR
A5DE5904 DECAL,COIN DOOR
A5DE5905 DECAL,SIDE LOCK
A5DE5907-R DECAL,RIGHT,CAB SIDE
A5DE5907-L DECAL,LEFT,CAB SIDE
A5DE5908 DECAL,JACKPOT WINDOW
A5DE5909 DECAL,MARQUEE ACRYLIC
A5DE5911 DECAL,LOCK FACE
A5DE5912 DECAL,LIGHT DIFFUSER
A5TR2800 TRIM,RUBBER EDGE,FOR MARQUEE
AACE5900 CABLE ASSY, CONTROL PANEL LIGHT
AACE5901 CABLE ASSY, LOCK SURROUND LEDS
AACE5902 CABLE ASSY, BOTTOM LIGHT HOLDER
AACE5903 CABLE ASSY, LOCK LATCH LEDS
AACE5904 CABLE ASSY, LEFT SIDE LIGHTS
AACE5905 CABLE ASSY, RIGHT SIDE LIGHT
AACE5908 CABLE ASSY, SPEAKER CABLE
AACE5909 CABLE ASSY, BUTTON SWITCH LIGHT
AACE5910 CABLE ASSY, MENU & COUNTER CABLE
AACE5911 CABLE ASSY, TICKET TRAY CABLE
AACE5912 CABLE ASSY, POWER SUPPLY CABLE
AACE5913 CABLE ASSY, COMMUN. CABLE
AACE5914 CABLE ASSY, POWER COMMUN. CABLE
AAPB2700 PUSHBUTTON ASSY
AACO1000 COUNTER,ASSY
A5CEAU010 CABLE,AUDIO STEREO,3.5MM
AAPS1013-PTL POWER SUPPLY ASSEMBLY
A5CBL4A-DOOR CABLE, DOUBLE COIN DOOR
AACE5915 CABLE ASSY, POWER CABLE TO LIGHT BD
AACE5916 CABLE ASSY, GROUND WIRE
AACE5918 CABLE ASSY, LIGHT BOARD JUMPER
AACE5920 CABLE ASSY,ADDRESSABLE LED LIGHT
AACE5921 CABLE ASSY, DBA CABLE
AACE5923 CABLE, INSIDE SIDE LOCKS TO HASP,LED
AACE5924 CABLE ASSY, CONTROL PANEL LED
AACE5925 CABLE ASSY, BUTTON CABLE LED
AACE5926 CABLE ASSY, MARQUEE LED LIGHTS
AACE5927 CABLE ASSY, OUTSIDE SIDE LOCK LED
AACE5929 CABLE ASSY, LINE FILTER JUMPER
AACE5930 CABLE ASSY, PLAYFIELD LIGHT
AACE5931 CABLE ASSY, MARQUEE SIDE LIGHT
AACE5932 CABLE ASSY, MARQUEE POWER CABLE
AACE1715 CABLE ASSY,GROUND STRAP
AACE5933 CABLE ASSY, MINI GEN TO LIGHT BD RBN
AACE5934 CABLE ASSY, SERVICE LIGHT
AACE5935 CABLE ASSY, FIRST NOTCH LIGHT BOARD
AACE5936 CABLE ASSY, SIDE CABINET LIGHTS
AACB5900 CIRCUIT BD, LIGHT CNTRL
A5CB2204A
CIRCUIT BD, SERIAL COMM
AACE8811 CABLE ASSY,SPEAKER
AAMB9A-SHD MOTHERBOARD W/16G SATA
AANEWGEN1-PJ/RBN
BD ASSY,MINIGEN,W/PHONO JACK&RIBBON
AACB5156 CIRCUIT BD, POWER DISTRIBUTION
AACB9503-PTL CIRCUIT BOARD ASSY, CHASE BOARD,
A5CB5901 CIRCUIT BOARD,NOTCH LED BOARD
W5HG1035 HINGE,23",DOUBLE BEND
W5KE5000 KEEPER,LOCK
A5CA1005 CASTER,250# LOAD,SWIVEL/LOCK
W5HG1025 HINGE,16",DOUBLE BEND
W5HG1045 HINGE,5.75" DOUBLE BEND
W5TM4000 T-MOLD,7/8""BLACK
A5CL1004 CLAMP,VERSA LATCH
1

Bay-Tek Pop the Lock Specifications

General

Brand	Bay-Tek
Model	Pop the Lock
Category	Arcade Game Machines
Language	English
