BCS Two Wheel Tractor Power Unit
Page 6 TWT/PU/0617
Controls Description
Models 710 - 728 - 738 - 740 - 750
(A) OPC LEVER (red lever that stops the machine when released)
(B) ENGINE STOP LEVER
(C) CLUTCH CONTROL LEVER
(D) GEAR LEVER (the location of different gears are shown on the selector)
(E) PTO LEVER (there is a safety device that prevents engagement with reverse gear)
(F) THROTTLE LEVER
(G) HANDLEBAR HEIGHT ADJUSTMENT LEVER
(H) STEERING COLUMN SWIVEL LEVER
(L) FORWARD/REVERSE LEVER (always engage the clutch before engaging this lever)
(M) DIFFERENTIAL LOCK LEVER
(N) PARKING BRAKE LEVER
(O) RIGHT BRAKE LEVER
(P) LEFT BRAKE LEVER
Power
Unit
Petrol Engine Diesel Engine
LAeq (1) LwA (2) m/sec
2
(3) LAeq (1) LwA (2) m/sec
2
(3)
710 85.0 101.7 3.13 n/a n/a n/a
728 85.9 101.7 3.13 n/a n/a n/a
738 85.9 101.7 3.13 89.6 105.2 2.06
740 85.9 101.7 3.13 89.6 105.2 2.06
750 85.9 101.7 5.79 99.1 108.0 18.28
(1) LAeq - ACOUSTIC PRESSURE: values expressed in equivalent dB(A).
(2) LwA - ACOUSTIC POWER: values expressed in dB(A).
(3) m/sec² - VIBRATION: average square value calculated at handlebars according to UNI EN 709.
Sound & Vibration Levels
