Product overview
KL2xxx and KS2xxx 19Version: 3.0.0
4-channel, digital output terminal, 24V
DC
The KL2404 and KL2424 digital output terminals connect the binary 24V control signals electrically isolated
with the actuators. The Bus Terminals each contain four channels, whose signal states are displayed by
LEDs. The variants KL2404 and KL2424 have different maximum output currents. The 4-channel Bus
Terminals enable the direct connection of four 2-wire sensors. Four ground connection points are provided.
2.4.1 KL2404, KL2424 – Technical data
Technical data KL2404 KL2424
Connection technology 2-wire
Number of outputs 4
Nominal voltage 24V
DC
(-15%/+20%)
Load type ohmic, inductive, lamp load
Max. output current 0.5A (short-circuit proof) per
channel
2.0A (short-circuit proof)
Short circuit current <2A <70A
Breaking energy (ind.) <150mJ/channel <1.7J/channel
Reverse polarity protection yes
Electrical isolation 500V (K-bus / field voltage)
Current consumption power contacts typ. 30mA + load
K-Bus current consumption typ. 9mA
Bit width in process image 4 outputs
Configuration no address or configuration settings required
Weight approx. 70g
Permissible ambient temperature
during operation
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature
during storage
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Vibration / shock resistance according to EN 60068-2-6 / EN 60068-2-27, refer also to
Installation instructions for enhanced mechanical load capacity
[}29]
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Installation position variable
Protection class IP20
Approvals
CE, cULus, ATEX [}33] CE, cULus, ATEX [}33], GL
