12
THINK Control Unit
INPUT/OUTPUT FUNCTIONS
THINK Control Unit
Terminal No. Function Description
1-2-3 Motor
Connection, 230Vac motor - single-phase:
1-Movement+capacitor/2-Common/3-Movement+capacitor
Connection, 400Vac motor - three-phase:
1-U/2-V/3-W
Check that the voltage selection jumper on terminals 36-37-38 is correctly positioned.
4-5 Flashing light
Connection of flashing light, 230Vac 40W max.
Connect a negative electric brake to this output.
5-6 AUX WARNING: Output, 230Vac 0,5A max.
7-8
Auxiliary
capacitor
Output N.O. (10A max) for pickup auxiliary capacitor. See wire diagram.
WARNING: 230Vac motor - single-phase only.
DISG Logic must be set ON
9-10 Courtesy light
Free N.O. contact (2A 150W) to control the Courtesy light which is timed according to the
TLS parameter.
11-12 24Vac Output, accessory power supply 24Vac/0,5A max
13-14 SCA/PhotoTest
Output, 24Vac/0,5A max. This can be preset as open gate indicator light or as checked
devices power supply (PhotoTest) through the TSTP logic.
In the event of presetting as PhotoTest, please refer to the diagram “Connection of checked
safety devices”
15 COM Common for limit switches and photocells
16 SWO Input, OPEN limit switch (N.C. contact)
17 SWC Input, CLOSE limit switch (N.C. contact)
18 PHOT 1 Input, Photocell 1 (N.C. contact). It can be disabled in the opening phase, see PHO1 logic.
19 PHOT 2 Input, Photocell 2 (N.C. contact). It can be disabled in the opening phase, see PHO2 logic.
20 PHOT 3 Input, Photocell 3 (N.C. contact). It can be disabled in the opening phase, see PHO3 logic.
21 PHOT 4 Input, Photocell 4 (N.C. contact). It can be disabled in the opening phase, see PHO4 logic.
22 STOP Input, STOP push-button (N.C. contact)
23 OPEN Input, OPEN push-button (N.O. contact).
24 CLOSE Input, CLOSE push-button (N.O. contact)
25 PED Input, pedestrian push-button (N.O. contact)
26 Step-by-step Input, step-by-step (N.O. contact)
27 COM Common for all other control inputs.
TECHNICAL DATA
Power supply
230 Vac 50/60 Hz
Output supply
1 motor 230Vac single-phase / 400Vac three-phase
Power maximum motor
230Vac single-phase: 800 W
400Vac three-phase: 2200 W
Output supply accessories
24Vdc 500mA max.
Protection level
IP54
Operating temp.
-20°C / +50°C
Radio receiver
Removable connector for radio receiver
