6 CONTROL PANEL (see "3.19 Control panel")
RESET
+
MENU
+
A
C
1 2 3
B
D
LED
7 PROGRAMMING THE BOILER
- Position the system’s master switch to the “on” position.
If necessary, the interface automatically goes to the clock menu. On the main screen the
icons , , and and ENTER come on while 00:00 is displayed with the rst two
digits blinking with a frequency of 0.5 sec ON, 0.5 sec OFF.
To set the time and day follow the following instructions:
 set the hour with the and arrows, then conrm with A
 set the minutes with the and arrows, then conrm with A
 set the day of the week with the and arrows. The segment of the day selected
blinks, press MENU at the icon
Enter
per to conrm the time and day setting. The clock
blinks for 4sec and then returns to the main screen
 to exit the time programming without saving the modied values, just press .
NOTE: It is possible to change the TIME and DAY settings also later by accessing the P1.02
parameter in the P1 menu, or by pressing the A+C keys for at least 2sec.
RESET
+
MENU
+
C
A
 If you need to set the language, select the menu P1 and conrm your choice using .
 Use the arrows to display parameter P1.01, then enter the submenu by pressing .
 Use the and buttons to set the desired language – see "3.20 Menu structure" . To
conrm your choice, press
Enter
.
USER GUIDE
Depending on the type of application, some of the functions described in this manual might not be available.
Each time that the boiler is powered a vent cycle is carried out lasting 6 min.
The display shows the message -AIR lighting up the icon RESET.
To interrupt the vent cycle press RESET.
Set the boiler to OFF by pressing .
8 FIRST COMMISSIONING
- Position the system’s master switch to the “on” position.
- Open the gas tap to allow fuel to ow
 With power on the backlight comes on, then all the icons and the segments come on for
1sec and in sequence the rmware revision is displayed for 3sec:
 Then the interface displays the status active at that moment.
Vent cycle
b
Each time that the boiler is powered, an automatic vent cycle is carried out lasting 6
min. When the air purging cycle is in progress, all heat requests are inhibited except
those for domestic hot water when the boiler is not set to OFF and -AIR is displayed
on the interface screen.
The purge cycle can be interrupted early by keeping key 2 (the icon RESET comes on).
The purge cycle can also be interrupted, if the boiler is not set to OFF, by a domestic hot
water request.
