9
KEYLESS CHUCK (FIGURE F)
To insert a drill bit or other accessory:
1. Grasp the rear half of the chuck (4)
with one hand and use your other
hand to rotate the front half in the
counterclockwise direction, as viewed
from the chuck end.
2. Insert the bit or other accessory fully into
the chuck, and tighten securely by holding
the rear half of the chuck and rotating the
front portion in the clockwise direction as
viewed from the chuck end.
WARNING: Do not attempt to tighten drill
bits (or any other accessory) by gripping the
front part of the chuck and turning the tool
on. Damage to the chuck and personal injury may occur when changing accessories.
SCREW DRIVING
For driving fasteners, the reversing button should be pushed to the left. Use reverse
(button pushed to the right) for removing fasteners. When moving from forward to reverse,
or vice versa, always release the trigger switch first.
ON BOARD BIT STORAGE
A bit storage slot is built-in to the area just above the battery pack.
DRILLING
• Use sharp drill bits only.
• Support and secure work properly, as instructed in the Safety Instructions.
• Use appropriate and required safety equipment, as instructed in the Safety Instructions.
• Secure and maintain work area, as instructed in the Safety Instructions.
• Run the drill very slowly, using light pressure, until the hole is started enough to keep the
drill bit from slipping out of it.
• Apply pressure in a straight line with the bit. Use enough pressure to keep the bit biting
but not so much as to stall the motor or deflect the bit.
• Hold the drill rmly with two hands to control its twisting action.
• DO NOT CLICK THE TRIGGER OF A STALLED DRILL OFF AND ON IN AN ATTEMPT
TO START IT. DAMAGE TO THE DRILL CAN RESULT.
• Minimize stalling on breakthrough by reducing pressure and slowly drilling through the
last part of the hole.
• Keep the motor running while pulling the bit out of a drilled hole. This will help reduce
jamming.
• Make sure switch turns drill on and off.
MAINTENANCE
Use only mild soap and damp cloth to clean the tool. Never let any liquid get inside the
tool; never immerse any part of the tool into a liquid.
IMPORTANT: To assure product SAFETY and RELIABILITY, repairs, maintenance and
adjustment (other than those listed in this manual) should be performed by authorized service
centers or other qualified service personnel, always using identical replacement parts.
TROUBLESHOOTING
Problem Possible Cause Possible Solution
• Unit will not start. • Battery pack not installed properly. • Check battery pack
installation.
• Battery pack not charged. • Check battery pack
charging requirements.
• Battery pack will not charge. • Battery pack not inserted into charger. • Insert battery pack into
charger until red LED
appears.
F
4

Black & Decker SS12C Specifications

General

Chuck type	Keyless
Hammer drilling	-
Adjustable speed	Yes
Number of gears	2
Idle speed (max)	1200 RPM
Drilling diameter in steel (max)	- mm
Product color	Black, Red
Input power	12 W
Power source	AC

Weight and Dimensions

Weight	- g
