Page 14
877-877-2269 | BlackBox.com
Chapter 2: Overview
2.5 Typical Application
Laptop
Laptop
LaptopLaptop
VGA IN
DP IN
HDMI IN
HDMI IN
Keypad
Control
Display
HDMI OUT
CEC Control
HDBaseT
Ethernet switch
Projector
HDMI
Amplifier in
ceiling speaker
RS-232
Figure 2-3. System Diagram.
