RESmart
©
Heated Humidifier User Manual V2.6
P3
Warnings & Cautions
IMPORTANT! • Read all instructions before using the humidifier.
• Use only with BMC RESmart devices whose instructions specify the use of this humidifier.
CAUTIONS! • Indicates the possibility of damage to the device.
• US federal law restricts this device to sale by or on the order of a physician.
• If fluids are spilled onto the humidifier platform, unplug the power cord from the AC
wall outlet and allow the humidifier platform to drain and dry before using.
• Take precautions to protect furniture from water damage.
WARNINGS! • Indicates the possibility for injury to the user or the operator.
• Use the humidifier only for its intended use as described in this manual.
• Use only accessories recommended by BMC.
• Never operate the humidifier if any of the parts are damaged, if it is not working
properly, or if the humidifier has been dropped or mishandled. Do not use the humidifier
if the water chamber is leaking or damaged in any way. Have any damaged parts replaced
before continuing use.
• Never touch the heater plate unless the humidifier is unplugged and the plate has cooled
down.
• This equipment is not suitable for use in the presence of a flammable anesthetic mixture
with air or with oxygen or nitrous oxide.
• Periodically inspect the power cord for signs of wear or damage. Replace if necessary.
•Do not operate the device in direct sunlight or near a heating appliance because these
conditions can increase the temperature of the air coming out of the device.
• When humidifier is used outside the specified ambient temperature range or humidity
range, the performance of humidifier will be compromised.
Symbols
Attention, Consult Type BF Applied part Class II (Double Insulated)
Accompanying Documents
DC Power IPX1 Drip-Proof, Vertical European CE Declaration
of Conformity
RESmart
©
Heated Humidifier User Manual V2.6
P11
Guidance and manufacturer's declaration - electromagnetic immunity
The RESmart is intended for use in the electromagnetic environment specified below. The user of the
RESmart should make sure that it is used in such an environment.
Immunity test
IEC 60601 test
level
Compliance level
Electromagnetic environment -
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floor should be wood, concrete or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for
power supply lines
±1 kV for
input/output lines
±2 kV for
power supply lines
±1 kV for
input/output lines
Mains power quality should be that of a
typical home or hospital.
Surge
IEC 61000-4-5
±1 kV
differential mode
±2 kV
common mode
±1 kV
differential mode
±2 kV
common mode
Mains power quality should be that of a
typical home or hospital.
Voltage dips,
short
interruptions and
voltage
variations on
power supply
input lines
IEC 61000-4-11
<5 % U
T
(>95% dip in U
T
)
for 0.5 cycle
40% U
T
(60% dip in U
T
)
for 5 cycles
70% U
T
(30% dip in U
T
)
for 25 cycles
<5% U
T
(>95% dip in U
T
)
for 5 s
<5% U
T
(>95 % dip in U
T
)
for 0.5 cycle
40% U
T
(60% dip in U
T
)
for 5 cycles
70% U
T
(30% dip in U
T
)
for 25 cycles
<5% U
T
(>95% dip in U
T
)
for 5 s
Mains power quality should be that of a
typical commercial or hospital
environment. If the user of the RESmart
requires continued operation during power
mains interruptions, it is recommended
that the RESmart be powered from an
uninterruptible power supply or from a
battery.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
0.3 A/m
If the pressure deviates more than is
indicated in the device specification, it
may be necessary to position the
RESmart further from sources of power
frequency magnetic fields. The power
frequency magnetic field should be
measured in the intended installation
location to ensure that it is sufficiently low.
NOTE: U
T
is the AC mains voltage prior to application of the test level.

BMC RESmart Specifications

General

Pressure Range	4-20 cmH2O
Data Storage	SD Card
Automatic Altitude Adjustment	Yes
Leakage Compensation	Yes
Device Type	CPAP
Sound Level	<30 dBA
Display	LCD
Modes of Operation	CPAP
Heated Humidifier	Optional

Summary

Warranty Information

Safety Warnings and Precautions

Important Warnings

Read all instructions before using the humidifier. Use only with BMC RESmart devices.

Cautions for Device Integrity

Indicates possibility of damage to the device. US federal law restricts sale by or on order of physician.

Operational Warnings

Never operate if damaged, not working, or dropped. Do not use if water chamber is leaking.

Safety Precautions for Use

Do not touch heater plate unless unplugged and cooled. Not for flammable anesthetic mixtures.

Symbol Explanations

Explanation of symbols like Attention, Type BF Applied part, DC Power, CE.

Product Features Overview

Humidifier Component Identification

Diagram identifying key parts: Outlet Port, Heater Plate, Water Chamber, Sensor, etc.

Feature Descriptions

Details on Power Connector, Heater Plate, Indicator Light, Air Inlet, Outlet Port, Water Chamber, Fill Line, Sensor.

Traveling and Security

CPAP Case Usage

Optional CPAP carrying case is for carry-on luggage only, not checked baggage.

Security Station Tips

Humidifier is medical equipment; carrying manual may help at security stations.

EMC Requirements and Guidance

Electromagnetic Emissions

Details on RF emissions, harmonic emissions, and voltage fluctuations/flicker emissions.

Electromagnetic Environment Guidance

Guidance on RF emissions being low, suitable for domestic and public low-voltage networks.

Product Specifications

Physical and Environmental Specs

Details on Size, Weight, Water Capacity, Temperature, Humidity, Pressure, and Electric Shock protection.

Operating and Performance Specs

Covers Power Requirements, Heater Settings, Maximum Operating Pressure, Pressure Drop, and Humidity Range.

Setting Up the Humidifier

Connection Procedure

Connect the humidifier to the RESmart device, ensuring complete connection.

Placement Guidelines

Place the RESmart device and humidifier on a firm, flat surface below sleeping position.

Setup Cautions

Do not turn on humidifier without water chamber. Protect furniture from water damage.

Daily Operation and Use

Filling the Water Chamber

Fill to the line with distilled water. Always remove chamber before filling. Avoid tilting.

Connecting and Operating

Connect tubing, press humidifier button on RESmart device. Adjust humidity setting as needed.

Automatic Shut-off

Humidifier shuts off automatically when airflow stops and reactivates if airflow restarts within 30 mins.

Cleaning Procedures

Water Chamber Cleaning

Clean daily. Cool down, empty, wash with mild detergent, rinse, and air dry. Inspect for leaks.

Humidifier Platform Cleaning

Wipe with a damp cloth and allow to air dry. Inspect for any damage and replace if necessary.

Silicone Tube Cleaning

Clean the silicone tube by wiping with an alcohol cotton stick and allow to air dry.

Service and Troubleshooting

Routine Servicing

The humidifier does not require routine servicing.

Malfunction Support

Contact home care provider for malfunctions. Do not open enclosure. Contact dealer for support.

Disposal Guidelines

Device and Accessory Disposal

Dispose of the device and accessories in accordance with local regulations.
