15. Modifying the front bumper trim
2/201101 29 2 160 471© BMW AG, Munich. (Z/Z) 28
15. Modifying the front bumper trim
E82/E88 and E90/E91 LCI cars with Performance
bumper only
Swap original left air guide for left air guide AQ/AR.
E82/E88 cars with standard or M bumper only
No modification necessary.
E90/E91 and E90/E91 LCI cars with standard
bumper only
Swap original left grille for left grille AS/AT.
Install the rod finisher (1) from the original grille.
E90/E91 cars with M bumper and E92/E93 cars
with standard bumper only
Remove fog light holder (1) and disconnect marked area (2).
Install fog light holder (1).
E90/E91 LCI cars with M bumper only
Place left brake air duct (1) against air guide AJ as shown,
transfer inner contour (2) and cut out.
