Replace defective bulb.
Bulb for taillight/brake
light
P25-2 / 12 V / 5 W / 21 W
To prevent contaminants from
being deposited on the new
bulb's glass surface, always use
a clean, dry cloth to hold it.
Press bulb 2 into fitting and
install turning clockwise.
Position tail light lens and in-
stall two screws 1.
Air cleaner
Replacing air filter insert
Removing right fairing side
panel ( 92).
Remove two screws 1.
Pull out connecting flange 2.
Pull suction pipe 3 off air filter
housing, take out of mount 4
and turn to side.
Disconnect plug 5.
8
86
z
Maintenance
