BMW 2013 S 1000R User Manual

Fasten brake line in holder 2
and install screw 1.
Adjust chain tension ( 131).
Bulbs
Replacing bulbs for low-
beam headlight
The alignment of the con-
nector may differ from the
illustration depending on the bulb
to be replaced.
Switch off ignition ( 41).
Remove right cover ( 128).
Remove screws 1 and tilt
headlight on right somewhat to
side.
Remove cover 1.
Disconnect plug connection 1.
Release wire spring 1 from
catch on left and right and fold
up.
Remove bulb 2 from the
socket.
9
140
z Maintenance

BMW 2013 S 1000R Specifications

General

Displacement	999 cc
Maximum Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Maximum Power	118 kW (160 hp) at 11, 000 rpm
Transmission	6-speed
Frame	Aluminum bridge frame, engine self-supporting
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum 2-sided swing arm
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 220 mm disc, single-piston caliper
ABS	Standard
Curb Weight	207 kg (456 lbs)
Fuel Capacity	17.5 l (4.6 US gal)
