Insert anti-theft alarm system 2
while hooking into bracket 3.
Install screw 4.
Connect connector 1 for anti-
theft alarm system.
Thread connector 1 with cable
through lower rear section 2.
Connect connector 1, position
and fasten cable tie arrow.
If the lamp defect warn-
ing message for racetrack
use is suppressed in the dis-
play, this must be activated in
the SETUP MENU under the
EQIP WARN LAMP function
before the motorcycle is put into
operation in road traffic.
Install the passenger seat
( 60).
Removing and installing
front turn indicator
Removing front turn
signal
The working steps de-
scribed here for the right
fairing side panel also apply logi-
cally for the left side.
Remove right cover ( 128).
Remove screw 1 and take off
turn indicator. Guide cable
through fairing side panel.
Protect connector on motorcy-
cle against contamination.
Install right cover ( 129).
Installing front turn signal
Remove right cover ( 128).
Guide cable through fairing
side panel.
5
86
z On the racetrack

BMW 2013 S 1000R Specifications

General

Displacement	999 cc
Maximum Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Maximum Power	118 kW (160 hp) at 11, 000 rpm
Transmission	6-speed
Frame	Aluminum bridge frame, engine self-supporting
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum 2-sided swing arm
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 220 mm disc, single-piston caliper
ABS	Standard
Curb Weight	207 kg (456 lbs)
Fuel Capacity	17.5 l (4.6 US gal)
