BMW 2013 S 1000R User Manual

Press and hold button 1 until
DTC warning lamp 2 changes
its display behavior.
DTC warning lamp begins
to light up.
Release button 1 within two
seconds.
DTC warning lamp remains
on.
The DTC function is switched
off.
Switching the DTC
function on
Press and hold button 1 until
DTC warning lamp 2 changes
its display behavior.
DTC warning lamp goes
out; if self-diagnosis has
not been completed, it begins to
flash.
Release button 1 within two
seconds.
DTC warning lamp remains
off or continues to flash.
The DTC function is switched
on.
If the coding plug is not in-
stalled, the ignition can also be
switched off and then on again
as an alternative.
If DTC warning light
lights up after switching
ignition off and on and then
continuing driving at following
minimum speed, an DTC error
has occurred.
min 3 mph (min 5 km/h)
Riding mode
Use of the riding modes
BMW Motorrad has developed 4
riding scenarios for your motor-
cycle from which you can select
the one matching your situation:
Riding on wet roads.
Riding on dry roads.
4
53
z Operation

BMW 2013 S 1000R Specifications

General

Displacement	999 cc
Maximum Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Maximum Power	118 kW (160 hp) at 11, 000 rpm
Transmission	6-speed
Frame	Aluminum bridge frame, engine self-supporting
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum 2-sided swing arm
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 220 mm disc, single-piston caliper
ABS	Standard
Curb Weight	207 kg (456 lbs)
Fuel Capacity	17.5 l (4.6 US gal)
