BMW G 450 X User Manual

Pull the instrument panel up
and out of the holders.
Turn battery-compartment
cover 1 counter-clockwise to
open.
Remove the battery.
Replace the spent battery.
Battery type and rated
voltage
Lithium battery CR 2430
3 V
Hold battery-compartment
cover 1 in position and turn
it clockwise to close.
Introduce the instrument panel
into its holders.
Install screws 2.
Connect plug 1.
Hold the bulb carrier with the
front mudguard in position.
Connect plug 4.
Install screws 3.
7
83
z Maintenance

BMW G 450 X Specifications

General

Displacement	449 cc
Bore x Stroke	98 mm x 59.6 mm
Compression Ratio	12.0:1
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Ignition	Digital CDI
Transmission	5-speed
Final Drive	Chain
Frame	Steel perimeter frame
Front Tire	90/90-21
Rear Tire	140/80-18
Fuel Capacity	7.5 L (2.0 US gal)
Engine Type	Single cylinder, 4-stroke
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Single disc
