BMW HP2 ENDURO User Manual

Push swivel lever 1 of the
brake lever forward and turn
it to the correct limit posi-
tion.
The swivel lever engages
with an audible click.
Handlebars
Adjustable handlebars
You can turn the handlebar
clamping blocks 180° to in-
crease or decrease handlebar
reach.
Short-reach position, handle-
bars toward rider.
Long-reach position, handle-
bars away from rider.
Adjusting handlebars
Make sure the ground is
level and firm and place the
motorcycle on its stand.
Remove small screws 1.
While holding the
handlebars, remove large
screws 2.
Remove top clamping
blocks 3.
Lift the handlebars clear
of the bottom clamping
blocks.
4
37
z Operation

BMW HP2 ENDURO Specifications

General

Displacement	1170 cc
Dry Weight	175 kg (386 lbs)
Seat Height	920 mm (36.2 inches)
Engine Type	Air-cooled, 4-stroke, flat twin (boxer)
Max Power	105 hp @ 7000 rpm
Max Torque	115 Nm @ 5500 rpm
Transmission	6-speed
Front Brakes	305 mm
Rear Brakes	Single disc, 265 mm, floating caliper
Fuel Capacity	13 liters
