BMW HP2 SPORT User Manual

Checking rear brake fluid
level
A low fluid level in the
brake reservoir can allow air
to penetrate the brake system.
This significantly reduces braking
efficiency.
Check brake fluid level
regularly.
Make sure ground is level and
firm and position motorcycle
vertically.
Read off brake fluid level at
reservoir 1.
In the event of brake pad
wear, the brake fluid level in
the brake-fluid reservoir falls.
Rear brake fluid level
Brake fluid DOT4
The brake fluid level must
not fall below the MIN mark.
(Brake-fluid reservoir horizon-
tal)
If brake fluid level drops below
permissible level:
Have the defect corrected as
soon as possible by a special-
ized workshop, preferably an
authorized BMW Motorrad re-
tailer.
10
124
z Maintenance

BMW HP2 SPORT Specifications

General

Displacement	1170 cc
Transmission	6-speed
Rear Brakes	Single 265 mm disc, 2-piston caliper
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Frame	Tubular steel space frame
Front Tyre	120/70 ZR17
Rear Tyre	190/55 ZR17
Engine Type	Air/oil-cooled, 4-stroke, two-cylinder boxer engine
Max Torque	115 Nm (85 lb-ft) at 6, 000 rpm
Fuel Capacity	16 liters
Dry Weight	178 kg
Clutch	Single dry plate clutch, hydraulically operated
Gearbox	Constant mesh 6-speed
Seat Height	830 mm
Weight, ready to ride, full tank	199 kg (439 lbs)
Front Suspension	Öhlins upside-down telescopic fork
