BMW HP2 SPORT User Manual

Tighten screws 1 of splash
guard hand-tight.
Installing rear wheel ( 131)
Tires
Checking tire pressure
Incorrect tire inflation pres-
sure results in poorer hand-
ing characteristics of the motor-
cycle and reduces the life of the
tires.
Ensure proper tire inflation
pressure.
At high road speeds, tire
valves installed perpen-
dicular to the wheel rim have a
tendency to open as a result of
centrifugal force.
In order to avoid a sudden loss of
tire inflation pressure, fit a valve
cap with rubber sealing ring to
the rear tire and make sure that
the cap is screwed on firmly.
Make sure ground is level and
firm and park motorcycle.
Check tire pressures against
data below.
Tire pressure, front
31.9 psi (2.2 bar) (With tire
cold)
Tire pressure, rear
36.3 psi (2.5 bar) (With tire
cold)
Tire pressure for sport
riding
30.5
±2.9
psi (2.1
±0.2
bar)
(With tire cold)
If tire pressure is too low:
Correct tire pressure.
Headlight
Adjusting headlight for
RHD/LHD traffic
If the motorcycle is ridden in a
country where the opposite rule
of the road applies, its asymmet-
ric low-beam headlight will tend
to dazzle oncoming traffic.
Have the headlight adjusted to
the relevant conditions by a spe-
cialized workshop, preferably an
authorized BMW Motorrad retail-
er.
5
79
z Operation

BMW HP2 SPORT Specifications

General

Displacement	1170 cc
Transmission	6-speed
Rear Brakes	Single 265 mm disc, 2-piston caliper
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Frame	Tubular steel space frame
Front Tyre	120/70 ZR17
Rear Tyre	190/55 ZR17
Engine Type	Air/oil-cooled, 4-stroke, two-cylinder boxer engine
Max Torque	115 Nm (85 lb-ft) at 6, 000 rpm
Fuel Capacity	16 liters
Dry Weight	178 kg
Clutch	Single dry plate clutch, hydraulically operated
Gearbox	Constant mesh 6-speed
Seat Height	830 mm
Weight, ready to ride, full tank	199 kg (439 lbs)
Front Suspension	Öhlins upside-down telescopic fork
