BMW HP2 SPORT User Manual

The start attempt is auto-
matically interrupted if bat-
tery voltage is too low. Recharge
the battery before you start the
engine, or use jump leads and a
donor battery to start.
Engine starts.
Consult the troubleshooting
chart if the engine refuses to
start. ( 150)
Warm-up phase
During the warm-up phase, the
LEDs 1 indicate the engine tem-
perature; the colder the engine
is, the more LEDs are switched
on. At the same time, a seg-
ment 2 for the recommended
maximum engine speed is shown
in the tachometer. A decreasing
number of LEDs light up as the
temperature rises and the recom-
mended maximum engine speed
increases. When the operating
temperature is reached, all LEDs
are switched off and the entire
engine speed range can be used.
The remaining segment in the
tachometer shows the maximum
speed.
If the indicated maximum engine
speed is exceeded, the LEDs
flicker.
Pre-ride check
The instrument cluster runs a
test of the 'General' warning light
when the ignition is switched on:
this is the "Pre-Ride-Check" The
'General' warning light shows first
red and then yellow, so that you
can check that it is in working
order. The test is aborted if you
start the engine before it com-
pletes.
If the startup animation is
switched on, the tachometer is
also activated.
Phase 1
General warning light shows
red.
Phase 2
General warning light shows
yellow.
If the 'General' warning light does
not show:
Some malfunctions cannot
be indicated if the 'Gener-
al' warning light cannot be dis-
played.
Check that the 'General' warning
6
87
z Riding

BMW HP2 SPORT Specifications

General

Displacement	1170 cc
Transmission	6-speed
Rear Brakes	Single 265 mm disc, 2-piston caliper
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Frame	Tubular steel space frame
Front Tyre	120/70 ZR17
Rear Tyre	190/55 ZR17
Engine Type	Air/oil-cooled, 4-stroke, two-cylinder boxer engine
Max Torque	115 Nm (85 lb-ft) at 6, 000 rpm
Fuel Capacity	16 liters
Dry Weight	178 kg
Clutch	Single dry plate clutch, hydraulically operated
Gearbox	Constant mesh 6-speed
Seat Height	830 mm
Weight, ready to ride, full tank	199 kg (439 lbs)
Front Suspension	Öhlins upside-down telescopic fork
