BMW K 1200 LT User Manual

19
General information and controls
1
Reversing
• Start the engine (b 76, 77)
• Select neutral
– Green neutral telltale light
k
ON (
b 10)
•Push lever1 of reverser all the
way toward position R until it
engages
L Note:
If lever 1 does not engage easily in
position R
– slightly rock the motorcycle
backwards and forwards until lever
1 engages.
– Yellow reverser telltale light
ON (
b 11)
• Press and hold down starter
button 2
– Carefully reverse the motor-
cycle
Reverser
2
1
10LTbkg6.book Seite 19 Mittwoch, 16. Mai 2007 10:35 10

BMW K 1200 LT Specifications

General

Displacement	1171 cc
Bore x Stroke	70.5 mm x 75 mm
Compression Ratio	10.8:1
Final Drive	Shaft drive
Fuel System	Electronic fuel injection
Torque	115 Nm at 5, 250 rpm
Transmission	5-speed
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual 320 mm discs
Rear Brakes	Single 285 mm disc
Power	98 hp (72 kW) at 6750 rpm
Wheelbase	1, 634 mm
