74
R 1200 CL
BMW Inspection I Procedures (600 Miles)
Torque Rear Wheel bolts
BMW inspections/services I
• Tighten the rear wheel studs in a
crosswise pattern.
Tightening torque:
Rear wheel studs; 105 Nm (77 ft. lb.)
Check the rear drive, wheel, and
swing arm bearings for play
BMW inspections/services I, III
• With motorcycle on accessory
stand, rock the rear wheel side to
side. Look for play at the rear drive,
wheel and swing arm bearings.
• If play is detected at any of these
locations, isolate and repair.
If play is detected at swing arm, re-
torque swing arm bearing
R 1200 CL Introduction
TTiigghhtteenniinngg ttoorrqquuee::
Bearing journal for rocker at right
side frame, 9 Nm (6.5 ft. lb.)
Bearing journal for rocker at right
side frame, 7 Nm (5.0 ft. lb.)
Lock Nut for bearing journal rocker
160 Nm (115.0 ft. lb.)
