2 Overview
2.1 Displays and controls
■
61 90 5 A1E 1B1
■
61 90 5 A1E 1B2
■
61 90 5 A1E 1B3
■
61 90 5 A1E 1B5
■
61 90 5 A1E 1B4
1. Housing cover
2. Vehicle plug connector holder
3. Vehicle plug connector (L)/Charging socket
with shutter (R)
4. LED display
5. Terminal block cover
6. Mounting bracket
7. Cable holder
