CP/BP Series
Unit Check-Out Sheet
UNIT CHECK-OUT SHEET
Customer Data
Customer Name ________________________________________________ Date __________________________________
Address ________________________________________________________
__________________________________________________________________
Phone __________________________________________________________ Unit Number _________________________
Unit Nameplate Data
Unit Make ______________________________________________
Model Number _________________________________________ Serial Number_______________________________
Refrigerant Charge (oz) _____________________
Compressor: RLA ____________________ LRA ______________
Blower Motor: FLA (or NPA) __________ HP _______________
Maximum Fuse Size (Amps) ________________
Minimum Circuit Ampacity (Amps) _________
Operating Conditions
Cooling Mode Heating Mode
Entering / Leaving Air Temp
______________ / _____________ ______________ / _____________
Entering Air Measured at:
_______________________________ ______________________________
Leaving Air Measured at:
_______________________________ ______________________________
Entering / Leaving Fluid Temp
______________ / _____________ ______________ / _____________
Fluid Flow (gpm)
______________________________ ______________________________
Compressor Volts / Amps
______________ / _____________ ______________ / _____________
Blower Motor Volts / Amps
______________ / _____________ ______________ / _____________
Source Fluid Type
_______________________________ ______________________________
Fluid Flow (gpm)*
______________________________ ______________________________
Fluid Side Pressure Drop*
______________________________ ______________________________
Suction / Discharge Pressure (psig)*
______________ / _____________ ______________ / _____________
Suction / Discharge Temp*
______________ / _____________ ______________ / _____________
Suction Superheat*
_______________________________ ______________________________
Entering TXV / Cap Tube Temp*
_______________________________ ________________________________
Liquid Subcooling*
_______________________________ ________________________________
* Required for Troubleshooting ONLY
Auxiliary Heat
Unit Make ______________________________________________
Model Number _________________________________________ Serial Number_______________________________
Max Fuse Size (Amps) __________________________________
Volts / Amps_____________________ /______________________
Entering Air Temperature
_______________________________
Leaving Air Temperature _______________________________
