TECHNICAL INFORMATION
Technical information
Technical information
The heat pump’s factory settings
This table indicates the factory settings for all the settings likely to be
changed by the fi tter.
Sensor table
This table indicates the values of the sensor
resistors to different temperatures.
Temperature (ºC) k
-40 154,00
-35 111,700
-30 81,700
-25 60,400
-20 45,100
-15 33,950
-10 25,800
-5 19,770
0 15,280
5 11,900
10 9,330
15 7,370
20 5,870
25 4,700
30 3,790
35 3,070
40 2,510
45 2,055
50 1,696
55 1,405
60 1,170
65 0,980
70 0,824
75 0,696
80 0,590
85 0,503
90 0,430
Menu Factory settings
1.1 temp. incr. / decr. +/- 4
1.2 Temp. Fine-tune 0º
1.3 Fine-tune the heat curve 0º
1.4 Heat curve hysteresis 5º
1.5 Mix. valve incr/decr 4
1.6 Adjust. mix. valve 0º
1.7 Fine tuning mix. valve curve 0º
1.8 Mixing valve curve neutral zone 3º
1.9 Max mixing valve curve at GT4 60º
1.10 inst. Int. temp 20º
1.11 Setting of room sensor 5
1.12 Setting holiday function 0 day
1.13 Remote control temperature Inactive
1.14 Summer disconnection setting 18º
2.1 No of hours for add. hot water 0 hours
2.2 Range for HW peak Inactive
2.3 Heating temp. setting 52º
2.4 Setting of DHW hysteresis 2º
4.1 Clock setting HP accord. to clock Inactive
4.1.1 Level of PAC setting +/- 0º
4.2 Timer control settings for add. heat Inactive
4.3 Clock setting DHW accord. to clock Inactive
5.2 Select capacity of conn. for additional heat 2/3
5.4 Select function add. heat only OFF
5.5 Select add. heat function yes
5.7 Select external control 0
5.10 Select P2 mode of funct. P2 running cont.
5.11 Select P3 mode of funct. P3 with Compres.
8.1 Setting add. heat time 60 minutes
8.3.4 Ramp time open 20 min
8.3.5 Ramp time closed 3 min
9.4 Min. temp pump inlet -10º
9.5 Min. temp. pump outlet -10º
