Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
FIG. 1
FIG. 2
MRF23EVS Fixed Base Router
NOTE: For tool specifications refer to the nameplate on your tool.
Sub-Base
Bit Rotation Arrow
MRF01
Fixed Base
MicroFine
Depth
Adjustment
Control
Base Clamp Lever
Trigger Switch
"Lock-On" Button
Trigger Switch
Handles
Motor-To-Base 5V Control
Connection Track
Speed Control Dial
Cord Swivel
MR23EVS Motor
Air Vents
