30 | English
2 609 141 026 | (1.7.13) Bosch Power Tools
The measuring tool monitors the correct
function for each measurement. When a de-
fect is determined, only the symbol shown
aside flashes in the display. In this case, or
when the above mentioned corrective
measures cannot correct an error, have the
measuring tool checked by an after-sales service agent for
Bosch power tools.
Maintenance and Service
Maintenance and Cleaning
Store and transport the measuring tool only in the supplied
protective pouch.
Keep the measuring tool clean at all times.
Do not immerse the measuring tool in water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any
cleaning agents or solvents.
Maintain the reception lens 17 in particular, with the same
care as required for eye glasses or the lens of a camera.
In case of repairs, send in the measuring tool packed in its
protective pouch 26.
After-sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Battery charge-control indicator (g) and “ERROR” indi-
cation in the display
Battery charging voltage not cor-
rect
Check if the plug-in con-
nection has been estab-
lished correctly and if
the battery charger is
operating properly.
When the unit symbol is
flashing, the battery is
defective and must be
replaced by a Bosch af-
ter-sales service.
Bluetooth® cannot be activated
The battery is too low. Charge the measuring
tool's battery.
No Bluetooth® connection
Failure of the Bluetooth® connec-
tion
Check the application on
your mobile termi-
nal/device.
Check if Bluetooth® is
activated on your meas-
uring tool and mobile
terminal/device.
Check your mobile ter-
minal/device for over-
load.
Reduce the distance be-
tween measuring tool
and your mobile termi-
nal/device.
Avoid obstructions
(e.g., reinforced con-
crete, metal doors) be-
tween measuring tool
and your mobile termi-
nal/device. Observe
clearance to electro-
magnetic disturbances
(e.g., WLAN transmit-
ters).
Data transmission via USB interface not possible
Software error Make sure that the soft-
ware runs correctly on
your computer or note-
book. For further infor-
mation, please refer to
the Bosch website at
www.bosch-pt.de
Micro USB cable Check the proper and
tight seating of the micro
USB cable.
Check the micro USB ca-
ble for damage.
Cause Corrective Measure
Battery charge-control indicator (g) or prolonged charge
duration indication n on the display
Charge duration clearly too long,
as charging current too low.
Only use the original
Bosch charger.
Measuring result not plausible
The target surface does not reflect
correctly (e.g. water, glass).
Cover off the target sur-
face
The laser beam outlet 18 or the re-
ception lens 17 are covered.
Make sure that the laser
beam outlet 18 or the re-
ception lens 17 are un-
obstructed
Wrong reference level set Select reference level
that corresponds to
measurement
Obstruction in path of laser beam Laser point must be
completely on target
surface.
The indication remains unchanged or the measuring tool
reacts unexpected after pressing a button
Software error Press the measuring
button 2 and the button
for clearing the internal
memory / On/Off 4 to re-
set the software.
Cause Corrective Measure
OBJ_BUCH-1956-002.book Page 30 Monday, July 1, 2013 11:28 AM
