Bosch Professional GLM 100 C User Manual

English | 21
Bosch Power Tools 2 609 141 026 | (1.7.13)
Technical Data
Digital Laser Rangefinder GLM 100 C
Article number
3 601 K72 7..
Distance measurement
Measuring range (max.) 100 m
A)
Measuring range (typical) 0.05–80 m
B)
Measuring range (typical under unfavourable conditions) 45 m
C)
Measuring accuracy (typical) ±1.5mm
B)
Measuring accuracy (typical under unfavourable conditions) ±2.5mm
C)
Lowest indication unit 0.1 mm
Indirect Distance Measurement and Vial
Measuring range –60° –+60°
D)
Grade measurement
Measuring range 0° –360° (4x90°)
D)
Measuring accuracy (typical) ±0.2°
E)/G)
Lowest indication unit 0.1°
General
Operating temperature –10 °C...+50 °C
F)
Storage temperature –20 °C...+50 °C
Allowable charging temperature range
+5 °C...+40 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
635 nm, <1 mW
Laser beam diameter (at 25 °C) approx.
–at 10m distance
–at 80m distance
6mm
48 mm
Setting accuracy of the laser to the housing, approx.
–Vertical
– Horizontal
±2mm/m
G)
±10mm/m
G)
Automatic switch-off after approx.
–Laser
– Measuring tool (without measurement)
20 s
5min
Weight according to EPTA-Procedure 01/2003
0.14 kg
Dimensions
51x111x30mm
Degree of protection
IP 54 (dust and splash water protected)
Data transmission
Bluetooth® Bluetooth® 4.0 (Classic and Low Energy)
I)
Micro USB cable
– Charging voltage
– Charging current
USB 2.0
5.0 V
500 mA
Battery
Li-Ion
Rated voltage
3.7 V
Capacity
1.25 Ah
Number of battery cells
1
Single measurements per battery charge, approx.
25000
H)
OBJ_BUCH-1956-002.book Page 21 Monday, July 1, 2013 11:28 AM

Bosch Professional GLM 100 C Specifications

General

Brand	Bosch
Model	Professional GLM 100 C
Category	Measuring Instruments
Language	English
