Bosch Tronic 3000T ES 2.5 User Manual

7
Information about the product
Tronic 3000T – 6 720 801 072 (2018/04)
Models ES8 (Vertical installation only)
Fig. 7
2.3 Technical data
Technical data Units ES 2.5 ES 4 ES 8
Capacity gallons 2.7 4.0 7.0 (Hor.) / 5.1 (Vert.)
Voltage VAC 110/120 for each model
Power at 120 VAC Watts 1440
Maximum water pressure psi 150
Weight (empty) Lbs 15.5 17.3 29.5
Amperage Amps 12.0 for each model
Phases 1
Temperature range °F 65 - 145
Recovery rate gallons/hour 6.8
Table 2
14 ½”
4½”
8½”
17.6”
17.6”
6720801072-05.1V
MAX
M
IN
O
F
F
ID
E
A
L
3”
11.4”
¾ NPT MALE”
1”

Bosch Tronic 3000T ES 2.5 Specifications

General

Capacity	2.5 gallons
Voltage	120V
Phase	Single
Water Connection	1/2" NPT
Installation	Wall-mounted
Temperature Range	65°F - 145°F (adjustable)
Amperage	12A
Wattage	1440W
