16
the stra in re Ii ef.
5. Remove 220-volt power tag from back of
equalizer cabinet.
6. Perform Reassembly Procedure.
7. Perform Controller Test Procedure.
110- TO 220-VOLT CONVERSION
NOTE: Conversions
must be performed with
the line cord disconnected from any power
source.
NOTE: Conversion is not possible unless 220-
volt power transformer and capacitor is or-
dered from factory. Check parts list. (Line
cord is an optional procedure depending on
customer needs.)
I. Follow Disassembly
Procedure for lower
220-VOLT TO 110-VOLT CONVERSION
PCB removal.
2. Remove I10-volt power transformer and
capacitor C-/, and install 220-volt compo-
nents. (See 802C parts list.)
3. Add a
jumper to LK-31 located in front
of the power transformer, near line cord. If
LK-32 and LK-33 are installed, remove.
(See Fig. 2/.)
4. Remove IIO-volt line cord (if necessary),
and
replace with 220-volt line cord. Make
certain the line cord is properly installed in
the strain relief.
5. Add a nO-volt label to back of equalizer
cabinet.
6. Perform Reassembly Procedure.
7. Perform Controller Test Procedure.
110-VOL T TO 220-VOLT CONVERSION
To:
Rack Mount Kit
FIG. 20
002C ACCESSORIES
From:
To:
FIG. 21
Loopstrap
109472
Brocket
109473
Hook
109474
Screw 118
108229-08
Cord Clip
1\ 1381
Instruction Sheet
122780
RACK MOUNT KIT PARTS LIST
Description
Port Number
Rock Mount Kit 121nl
PoneI 121859
Mounting Brocket 109643
Screw-Sh Met 114 x .25L 1031\8-04
Hex Nut/Wast- #8-32 100413-2
Screw-Truss He! 10-32x.5L
111200-08
Instruction Sheet 121861
Carton
110339
FIG. 22
Description
Transit Kit
802C TRANSIT KIT
Port Number
123037
FIG. 23
