Bose CineMate 130 User Manual

English - 5
Contents
Introduction
About your CineMate
®
130 home theater system........................................................... 7
System Features ........................................................................................................... 7
Introducing SoundTouch™ from Bose
®
.................................................................... 7
Unpacking the system ......................................................................................................... 8
Placement guidelines .......................................................................................................... 9
Setting Up the Acoustimass
®
Module
Attaching the rubber feet to the Acoustimass module ................................................ 10
Connecting the Acoustimass module to power ............................................................. 11
Setting Up the Console
Connecting the console to your TV’s HDMI™ ARC connector ........................................ 12
TVs without an HDMI™ ARC connector ............................................................................. 13
Use a secondary connection in the following configurations.............................. 13
Connecting the console to other sources ........................................................................ 13
Connecting to non-HDMI™ compatible sources ............................................................. 14
Audio-only sources ...................................................................................................... 14
Setting Up the Soundbar
Connecting the soundbar ................................................................................................... 15
Attaching the optional extension feet to the soundbar ............................................... 16
Wall mounting the soundbar ............................................................................................. 16
Connecting the System to Power
Connecting the soundbar to power .................................................................................. 17
Connecting the console to power ...................................................................................... 17
Starting Up the System
Installing the remote control’s batteries ......................................................................... 18
Powering on the system...................................................................................................... 18

Bose CineMate 130 Specifications

General

Disc types supported	No
Optical disc player type	Not included
Internet radio	Yes
Apple docking compatibility	-
RMS rated power	- W
Audio output channels	- channels
Subwoofer type	Active subwoofer
Product color	Black
HDMI in	4
Number of HDMI outputs	1
AC input voltage	100-240 V
Package weight	20000 g

Weight and Dimensions

Main unit weight	1490 g
Subwoofer weight	6300 g
Center speaker weight	3500 g
Main unit dimensions (WxDxH)	313 x 208 x 64 mm
Subwoofer dimensions (WxDxH)	197 x 286 x 375 mm
Center speaker dimensions (WxDxH)	935 x 61 x 124 mm
