Bose ControlSpace EX-1280C Service Manual

101
OLED PCB PART LIST
Diodes (continued)
Reference
Designator
Description Vendor Vendor Part Number Note
D6 ZENER, 500MW, 12V, SOD-123 DIODES INC MMSZ5242B-7-F
D7 215MA, 70V, DUAL, SERIES, SOT-23-3 ON SEMI BAV99LT1G
D8 ZENER, 2.7V, 500MW, SOD123 DIODES INC BZT52C2V7-7-F
Transistors
Reference
Designator
Description Vendor Vendor Part Number Note
Q1 NPN, 40V, 0.2A, SOT-23-3 FAIRCHILD MMBT3904
Q2 NPN, 40V, 0.2A, SOT-23-3 FAIRCHILD MMBT3904
Q3 NPN, 40V, 0.2A, SOT-23-3 FAIRCHILD MMBT3904
Integrated Circuits
Reference
Designator
Description Vendor Vendor Part Number Note
U1 ENCODER, 15MM, FLATTED, 20 DET CTS 290VAA5F201B2
Miscellaneous
Reference
Designator
Description Vendor Vendor Part Number Note
J1 CONN, FFC, VERT, 24 POS, 0.50MM, SMD FCI 62674-241121ALF
J2 CONN, FFC, BOTTOM, 20 POS, 0.50MM, R/A JST 20FLZ-RSM2-TB(LF)(SN)
LED1 LED, DUAL, WHT/RED, 3.5MM X 2.8MM KINGBRIGHT AAA3528QWDSURKS

Bose ControlSpace EX-1280C Specifications

General

Network Connectivity	Ethernet
Software	ControlSpace Designer
Sample Rate	48 kHz
A/D and D/A Converters	24-bit
Power Supply	100-240 VAC, 50/60 Hz
Category	Signal Processor
Control Interface	Ethernet
Connectivity	Ethernet
Signal Processor Type	Digital Signal Processor
Audio Inputs	12 x Analog, 8 x Digital (Dante)
Audio Outputs	8 x Analog, 8 x Digital (Dante)
Dimensions	19 x 1.75 x 10.5 inches (483 x 44 x 267 mm)
