Bose ControlSpace EX-1280C Service Manual

83
POWER SUPPLY PCB PART LIST
Capacitors
Reference
Designator
Description Vendor Vendor Part Number Note
C1 CER, 2.2NF, 250V, 20%, D11.5 TDK CD12-E2GA222MYNS
C2 CER, 2.2NF, 250V, 20%, D11.5 TDK CD12-E2GA222MYNS
C3 CER, 2.2NF, 250V, 20%, D11.5 TDK CD12-E2GA222MYNS
C4 MET PP, 0.47UF, UL/CSA, 305V, 20% Epcos B32922C3474M000
C5 NPO, 470PF, 50V, 5%, 125C, 0603 Murata GRM1885C1H471JA01D
C6 SMT, 1206, 47PF, 1000 volt, C0G, 5% Murata GRM31A5C3A470JW01D
C7 SMD, E, 33UF, 63V +/-20%, 105C UCC EMZA630ADA330MHA0G
C8 SMD, E, 100UF, 63V +/-20%, 105C UCC EMVE630ADA101MJA0G
C9 E, 150UF, 400V, 20%, 105C, D25.4 UCC EKMQ401VSN151MQ25W
C10 SMT, 1206, 3300pF, 1000V, 10% Kemet C1206C332KDRACTU
C11 SMD, E, 10uF, 35V, 20%, 105C NIPPON EMVE350ADA100ME55G
C14 E, 1500UF, 25V, 20%, 105C, D12.5 UCC EKZE250ELL152MK25S
C15 E, 1500UF, 25V, 20%, 105C, D12.5 UCC EKZE250ELL152MK25S
C16 NPO, 27pF, 50V, 5%, 125C, 0603 Murata GRM1885C1H270JA01D
C17 NPO, 27pF, 50V, 5%, 125C, 0603 Murata GRM1885C1H270JA01D
C18 SMD E, 470UF, 25V, 20%, 105C United Chemi EKZE250ELL471MH20D
C19 SMD E, 470UF, 25V 20%, 105C United Chemi EKZE250ELL471MH20D
C20 SMD, E, 100UF, 25V, 20%, 105C UCC EMVY250ADA101MF80G
C21 SMD, E, 100UF, 25V, 20%, 105C UCC EMVY250ADA101MF80G
C22 SMD, E, 100UF, 25V, 20%, 105C UCC EMVY250ADA101MF80G
C23 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C24 SMD, E, 47UF, 35V, 20%, 105C Nichicon UUD1V470MCL1GS
C25 X7R, 1NF, 50V,10%, 0603 Murata GRM188R71H102KA01D
C26 X7R, 4.7UF, 25V, 10%, 1206 Murata GRM31CR71E475KA88L
C27 X7R, 4.7UF, 25V, 10%, 1206 Murata GRM31CR71E475KA88L
C28 SMT, 0805, 1uF, 25V, X7R, 10% Murata GRM21BR71E105KA99L
C29 SMT, 0805, 1uF, 25V, X7R, 10% Murata GRM21BR71E105KA99L
C30 SMT, 1206, 47pF, 1000 volt, C0G, 5% Murata GRM31A5C3A470JW01D
C31 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C32 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C33 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C34 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C35 SMT, 0805, 0.33uF, 25V, X7R, 10% Murata GRM21BR71E334KA01L
C36 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C37 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C38 SMT, 1206, 47pF, 1000 volt, C0G, 5% Murata GRM31A5C3A470JW01D
C39 X7R, 0.1UF, 630V, 10%, 1808 Kemet C1808X104KBRACTU
C40 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C41 X7R, 100NF, 50V, 10%, 0603 Murata GRM188R71H104KA93D
C42 X7R, 0.1UF, 630V, 10%, 1808 Kemet C1808X104KBRACTU
C43 CER, 2.2NF, 250V, 20%, D11.5 TDK CD12-E2GA222MYNS
C44
SMD, E, 10UF, 35V, 20%, 105C
UCC EMVE350ADA100ME55G
