Bose ControlSpace EX-1280C Service Manual

92
ACOUSTIC ECHO PCB PART LIST
Resistors (continued)
Reference
Designator
Description Vendor Vendor Part Number Note
R269 10K, OHM, 1/16W, 0402, 1% Yageo RC0402FR-0710KL
R272 10K, OHM, 1/16W, 0402, 1% Yageo RC0402FR-0710KL
R273 10K, OHM, 1/16W, 0402, 1% Yageo RC0402FR-0710KL
R274 10K, OHM, 1/16W, 0402, 1% Yageo RC0402FR-0710KL
R284 2.2K, 1/16W, 0402, 1% Yageo RC0402FR-072K2L
R285 2.2K, 1/16W, 0402, 1% Yageo RC0402FR-072K2L
R286 10K, OHM, 1/16W, 0402, 1% Yageo RC0402FR-0710KL
R303 75 OHM, 1/8W, 0805, 1%, T&R Yageo RC0805FR-0775RL
R307 75 OHM, 1/8W, 0805, 1%, T&R Yageo RC0805FR-0775RL
R308 0 OHM, 1/16W, 0402, 1%, T&R Yageo RC0402FR-070RL
RN1 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
RN2 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
RN3 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
RN4 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
RN5 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
RN6 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
RN7 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
RN8 RES NETWORK, 8P, 10K, 1/16W, ISO, 5% Yageo YC124-JR-0710KL
Capacitors
Reference
Designator
Description Vendor Vendor Part Number Note
C1 X7R, 0.1UF, 25V, 10%, 0402, 125C, T&R TDK C1005X7R1E104KT000F
C2 X5R, 4.7UF, 10V, 10%, 85C, 0603, T&R Yageo CC0603KRX5R6BB475
C3 X7R, 0.1UF, 25V, 10%, 0402, 125C, T&R TDK C1005X7R1E104KT000F
C4 X5R, 4.7UF, 10V, 10%, 85C, 0603, T&R Yageo CC0603KRX5R6BB475
C5 X5R, 4.7UF, 10V, 10%, 85C, 0603, T&R Yageo CC0603KRX5R6BB475
C6 X7R, 0.1UF, 25V, 10%, 0402, 125C, T&R TDK C1005X7R1E104KT000F
C7 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C8 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C9 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C10 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C11 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C12 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C13 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C14 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C15 X5R, 4.7UF, 10V, 10%, 85C, 0603, T&R Yageo CC0603KRX5R6BB475
C16 X7R, 0.1UF, 25V, 10%, 0402, 125C, T&R TDK C1005X7R1E104KT000F
C17 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C18 22UF, X5R, 10V, 20%, 0805, 85C, T&R TDK C2012X5R1A226MT0J0E
C19 X7R, 0.1UF, 25V, 10%, 0402, 125C, T&R TDK C1005X7R1E104KT000F
C20 X5R, 4.7UF, 10V, 10%, 85C, 0603, T&R Yageo CC0603KRX5R6BB475
C21 X7R, 0.1UF, 25V, 10%, 0402, 125C, T&R TDK C1005X7R1E104KT000F
